Sourcemeter, SM-1000C

Product Description

We manufacture, export and supply Experimental setup of Sourcemeter. By linking source and measurement circuitry in a single unit, this instrument offer a variety of advantages over systems configured with separate source and measurement instruments. For example, they minimize the time required for test station development, setup, and maintenance, while lowering the overall cost of system ownership. Test process itself is simplified by eliminating many of the complex connection issues associated with using multiple instruments.

A Source Meter has the basic feature of sourcing as well as sinking power. The terms sourcing and sinking describe power flow into and out of a device, respectively. Devices that are sourcing power are delivering power into a load, while devices that are sinking power behave like a load, absorbing power that is being driven into them and providing a return path for current. This is clearly represented by the attached diagram. The present unit however operates in Quadrants I and II only, implying that the current source is always positive.

The setup is complete in itself, computer connectivity through SES-CAMM.
